WEINGARTNER CNC SPIRAL FINISHING LATHE
Model FINISH 320-7000
Serial number SN: 0138
Year of manufacture 1997
Maximum polishing diameter 12.6”
Maximum part length 275”
Maximum polishing length 255”
Spindle center height 49”
Cross slide stroke range 2´- 6”
Quill diameter 8.6”
Polishing head degrees swivel angle +/- 45’
Central lubrication Yes
Chip conveyor Yes
Polishing head enclosure Yes
Flute polishing capacity 2 – 7 flutes
Price: $ 195,000. FOB Houston, TX.
SUBJECT TO PRIOR SALE
Comments: New cost on this machine is about $ 850,000.
This unit was running when removed from service.
Attached pictures were from the plant installation.
Specifications need to be confirmed.
