DAYTON Vertical Band Saw
Model
4TK02A
Operation
Manual
Rectangular Cutting Capacity -
Horizontal10-3/4 in x 18 in
Throat Depth - Vertical
18 in
Round Cutting Capacity - Horizontal10-3/4 in
SFPM Range
82 to 385
Miter Angle Range
0°
Number of Speed Settings
Continuous
Material Application
Metal; Wood
Max. Blade Width
5/8 in
Min. Blade Width
1/8 in
Cutting Capacity Square
10.75 in
Blade Thickness
0.035 in
Blade Wheels Dia.
18 in
Max. Blade Length
141 in
Min. Blade Length
138 in
Table Dimensions
21-1/2 in x 23-1/2 in
HP
1.5 hp
Voltage
115/230V ACPhase1
Amps AC
18.0/9.0 A 60 Hz
Overall Depth
30 in
Overall Height
75 in
Overall Width
37 in
Price: $7,500
Features
Includes Built-In Chip Chute; Cast Iron
Pulleys; Chip Blower; Eye Bolt; Industrial Rated Heavy Duty Speed
Reducer; NEMA Frame Motor with Power Cord; Push Button Magnetic
Power Switch; Rip Fence; Rubberized Cast Iron Wheels; Wheel Cleaning
BrushHeavy Gauge Steel Construction;Cast Iron Wheels; Industrial
Rated Heavy Duty Speed Reducer; Pulleys; Table and LED Blade Speed
IndicatorCurrent18.0/9.0 AUNSPSC27112709 Country of OriginTaiwan
(subject to change)
