Acra Milling Machine

Model: AM5AC

Standard Equipment

Hardened & Ground Table & Ways
Double Wall Construction
Coolant System
Splash Guard
TURCITE On The X & Y Axis
Z Axis Power Rapid
Quill Heat Treat Hardened & Chromed

Specifications

Table Size: 12" x 58"
Longitudinal Travel (X Axis): 42"
Cross Travel (Y Axis): 15 1/2"
Vertical Knee Travel (Z Axis): 16"
Over Ram Travel: 21"
T-Slot Number , Size: 3 , 5/8"
Spindle Motor: #40 Taper
Spindle Speed: Inf. Vari.
Spindle RPM: 50~5,000 RPM
Quill Diameter: 4"
Quill Travel: 5"
Motor: 5 HP
Voltage: 220V 1PH/3PH
Weight: 3,960 LBS
Dimension WxL: 72 1/2" x 58 1/2"

Features

Class 7 Angular Contact Bearings
Certified Meehanite Casting
Build In Power Knee
Auto Lube System
Ram Locking System U.S. Patent #4990039 Utilizing 6 T-Bolts
#40 NST STD. w/ Erickson Thread
Hand Scraped Turret-Column Ways
Square Y & Z Ways
Dust Cover For Knee And Crossfeed Ways
Precision Hardened And Ground Table With Turcite
Double Wall Column
Built-In Coolant Tank In Base

Price: $7,500
